KEY FEATURES
• Single transmitter system with the option for a spare at time of order
• Receiver and transmitter are completely programmable in the field
• Pre-wired receiver with 10 ft cable
• Quick connect plug (option)
• 2 speed pushbutton
• 2 year warranty
• Up to 12 hours of battery life under normal operating conditions
• Transmitter turns to stand-by mode after 4 minutes
• Frequency change in field via transmitter
• 70 operating channels to choose from Auto-scanning feature
• Battery charger with second spare battery
• Stop circuitry interlock
• Motion relays in series
• Self-diagnostic alarm codes
• Operation frequency: 902-928 MHz fully compliant with FCC Part 15
• Operating temperature: -4°F~150°F
• Relays rated 8A @ 230VAC
• Response time = 25ms
• Operation range up to 100 m (328 ft.)
• Antenna impedance 50 ohms
• 5 pulsed transmissions every 100ms for safe operation
• No license required
STANDARD OPTIONS
• First come first served
• Pitch & catch
• Tandem crane operation
• IR range limiter
TRANSMITTER SPECIFICATIONS
• Ergonomic and lightweight
• Transmitter enclosure: IP65 (NEMA 4 type)
• Audible and visual low powerwarning
• Clear detent 2-step buttons
• RF output power: 5 mW
• Large E-stop
• Long life 700mAh, 4.8v battery (NIMH)
• Internal antenna •
• Programs receiver from ground through RF communication (no need to climb on crane to change
frequency or address)
• Hand strap
• 6 or 10 button configuration (custom switches available)
RECEIVER SPECIFICATIONS
• Receiver enclosure: IP55 (NEMA 12 type)
• Power interruption protection
• Relays contact failure detection circuit
• Shock resistant hard plastic enclosure
• Internal integrated antenna (external antenna optional) Supply voltage 230VAC ± 10%, 50Hz,
115VAC, 60Hz, Optional 12 or 24VDC
• Power consumption 20W
• Up to 21 output relays
.
.
.
|
