KEY FEATURES
Single transmitter system with the option for a spare at time of order
Receiver and transmitter are completely programmable in the field
Pre-wired receiver with 10 ft cable
Quick connect plug (option)
2 speed pushbutton
2 year warranty
Up to 12 hours of battery life under normal operating conditions
Transmitter turns to stand-by mode after 4 minutes
Frequency change in field via transmitter
70 operating channels to choose from Auto-scanning feature
Battery charger with second spare battery
Stop circuitry interlock
Motion relays in series
Self-diagnostic alarm codes
Operation frequency: 902-928 MHz fully compliant with FCC Part 15
Operating temperature: -4°F~150°F
Relays rated 8A @ 230VAC
Response time = 25ms
Operation range up to 100 m (328 ft.)
Antenna impedance 50 ohms
5 pulsed transmissions every 100ms for safe operation
No license required
STANDARD OPTIONS
First come first served
Pitch & catch
Tandem crane operation
IR range limiter
TRANSMITTER SPECIFICATIONS
Ergonomic and lightweight
Transmitter enclosure: IP65 (NEMA 4 type)
Audible and visual low powerwarning
Clear detent 2-step buttons
RF output power: 5 mW
Large E-stop
Long life 700mAh, 4.8v battery (NIMH)
Internal antenna
Programs receiver from ground through RF communication (no need to climb on crane to change
frequency or address)
Hand strap
6 or 10 button configuration (custom switches available)
RECEIVER SPECIFICATIONS
Receiver enclosure: IP55 (NEMA 12 type)
Power interruption protection
Relays contact failure detection circuit
Shock resistant hard plastic enclosure
Internal integrated antenna (external antenna optional) Supply voltage 230VAC ± 10%, 50Hz,
115VAC, 60Hz, Optional 12 or 24VDC
Power consumption 20W
Up to 21 output relays
.
.
.
|
