KEY FEATURES:
Dual transmitters standard with all systems
76 communication channels (Crystal)
IP65 protection (NEMA 4 type)
Glass fiber-reinforced nylon-6 receiver/transmitter casings
300 and 400 MHz frequency (depending on model)
Operating temperature -31°F - 167°F (-35°C - 75°C)
Auto-shut-down (programmable)
Optional antenna extension for longer control range (up to 1500 ft.)
No license required
FCC approved
TRANSMITTER SPECIFICATIONS
Single and two-step buttons (three step capability using start button)
Up to 10 button configurations
Controls up to 5 motions (or other configurations)
E-stop button (except PWRM-21-2)
Removable on/off/start key switch (except PWRM-21-2)
Lightweight design
— 5 oz (PWRM-21-2)
— 9 oz (PWRM-21-4 & 6)
— 11 oz (PWRM-24)
Battery LED indication
2 million push button cycle
Control range
— 150 ft (PWRM-21-2)
— 250 ft (PWRM-21-4 & 6)
— 500 ft (PWRM-24)
2AA alkaline batterie
Transmitter protective nylon case
2 style legend sheets (custom available)
RECEIVER SPECIFICATIONS
Compact and lightweight
Supply voltage 110/220 VAC (other available)
10 A @ 250 VAC rated relays
Pre-wired receivers with 10 ft cable
.
.
.
|
